Gold Processing Machineries
Star Trace is one of the leading project suppliers for gold plants and we work closely with our customers to fulfil their specific needs. Our array of gold processing machineries includes: Slurry Pumps, Gold Concentrator, Shaking Table for Gold, Mineral Jig for Gold, Spiral Separator, Dewatering Screen for Gold, Ball Mill for Gold, Jaw Crusher, Cone Crusher, Belt Conveyors.
- Gold Processing Plants
Star Trace offers turnkey solutions for gold processing plants. Specialized in the fabrication of these machines for 25 years and this enables us to be in a leading position in the field of gold processing plant & equipment. We specialize in gold processing plants, gold trommel plants and portable gold trommel plants.
Slurry Pumps for Gold Processing
- Heavy duty slurry
- Medium duty slurry
- Process pumps
- Vertical slurry pumps
- Ash slurry pumps
Shaking Tables For GoldCONSTRUCTION
Mineral Jig for goldTheory Of Operation
The In-line pressure Jig is unique in its design and use of jigging concepts. The unit is fully encapsulated and pressurised and combines a circular bed with a moveable sieve action. The encapsulation allows the STPL to be completely filled with slurry and water.
As a result, slurry velocity is slowed and water surface tension eliminated improving recovery potential. The screen is pulsed vertically by a hydraulically driven shaft. Length of stroke and speed of up and down stroke can be varied to suit the application. Screen aperture and ragging dimension and material can also be altered for the application.
STAR TRACE pressure Jig is a high yield, high recovery gravity separation device. It has been successfully installed in both alluvial and hard rock applications. Significant advantages have been achieved in grinding circuits where coarse heavy minerals or waste material have been recovered for preferential treatment prior to over grinding.
The mineral jig operated to recover free gold, sulphides, native copper, native silver, tin/tantalum, diamonds and garnet. Installations are also planned for coal, lead remediation, magnetite, mineral sands and iron ore recovery. Typically units are installed in the recirculating load with STPL feed consisting of up to 14mm mill discharge or cyclone underflow.
Spiral Separators for gold
Spirals are gravity concentrators and separate minerals of different specific gravity according to their relative movement in response to gravity, centrifugal force and other forces in the fluid medium. It has extremely good performance and effects in processing placer of beach, riverside, seashore and stream.
Star Trace spirals are made of polyurethane lined fiber glass with wearable corundum inner surface. Generally there are 5 turns in one start, single, twin, triple and quad starts available per column to suit capacity requirements.
- Rutile, ilmenite and zircon concentration.
- Iron ore, chromite and manganese beneficiation.
- Tin, tantalum and ore concentration.
- Gold, native copper and base metal recovery.
- Silica sands processing.
- Titano-magnetite concentration.
Dewatering Screen for gold
Whilst enjoying immense popularity for many years on small horizontal and inclined screens, STAR TRACE is the first company in the India to perfect this simple drive arrangement on large horizontal and inclined screens.
This single development has resulted in tremendous advantages as far as reduced maintenance, compactness and simplicity are concerned.
Besides the simplicity of the drive, many other features have been incorporated to provide a machine which is specifically designed for heavy duty applications, long life and low operating and maintenance costs at a competitive price. The standard range of screens from 300x900mm to 3000x9000mm in single and multi-deck configuration.
A Ball Mill a type of grinder is a cylindrical device used in grinding (or mixing) materials like ores, chemicals, ceramic raw materials and paints.
Ball Mills rotate around a horizontal axis, partially filled with the material to be ground plus the grinding medium. Different materials are used as media, including ceramic balls, flint pebbles and stainless steel balls. An internal cascading effect reduces the material to a fine powder.
Industrial ball mills can operate continuously fed at one end and discharged at the other end. Large to medium-sized ball mills are mechanically rotated on their axis but small ones normally consist of a cylindrical capped container that sits on two drive shafts (pulleys and belts are used to transmit rotary motion).
The crushing chamber of Jaw Crusher is composited by stationary jaw and movable jaw.The crushing work simulates the movement of animals which use two jaw crushers to crush materials.
Jaw Crusher is widely used in quarry, mining, metallurgy industry, building material, highway, railway and chemical industry etc.
The largest compression resistance of the material to be crushed is 320m pa. It is ideal for the primary crushing. It features high reduction ratio, easy operation, simple construction, repeatable performance, easy maintenance and low consumption.
